Bennett Marine 12" x 9" Bolt Electric Trim Tab Systems with Rocker Control, Complete Kit BOLT129, 12V DC
BOLT ELECTRIC TRIM TAB SYSTEM BOLT129 - Trim tabs for boats include a Bolt rocker switch control, two actuators with 6 ft wire harnesses and waterproof connectors, and two stainless steel trim tabs with mounting plates 12" x 9".
ELECTRIC ACTUATORS - Adjustable upper hinge. Completely waterproof, submersible, and maintenance-free. Each 12-volt actuator comes with 6 ft wire harnesses and waterproof connectors. Mfg. PN# BEA3000 - Actuator stroke: 2.5" | Tip-to-tip length: 13.75". The system is designed for typical transom angles between 10-15 degrees, with compatibility extending to outliers up to 17 degrees. At a 17-degree transom angle, the required vertical installation space needed is 13.7".
ROCKER SWITCH CONTROL - For electric systems only. Attractive ergonomic design with positive click action for precise trim tab adjustment. Mfg. PN# BRC4000.
ACTUATOR WIRE HARNESSES - Two 20 ft wire harnesses with waterproof connectors included. Mfg. PN# BAW2020.
HIGH PERFORMANCE TRIM CONTROL - Eliminates boat porpoising, improves stability at high speed, and helps the boat plane faster with better control and a smoother ride in rough water conditions.
SPECIFICATIONS:
Trim Tab Size: 12" x 9"
Voltage: 12 Volts
Trim Tab Actuator: Electric System
Actuator Stroke: 2.5"
Actuator Tip-to-tip length: 13.75"
Vertical transom Space Required: Adjustable Upper Hinge (BEA3000): The system is designed for typical transom angles between 10-15 degrees, with compatibility extending to outliers up to 17 degrees. At a 17-degree transom angle, the required vertical installation space needed is 13.7"
Actuator Chord: 6 Ft
Trim Tab Control Type: Rocker Switch
Working forces: Actuation force: 750Lb. | Return Force: 750Lb. (This is max capacity; typically operates at 250 lbs)
Current draw: 10 - 30 Amp - 30 Amp max - will usually never get to this point
Type: Trim Tab Kits (Edge Mount)
Mounting Hardware: Mounting Hardware (Included)
Warranty Details: Limited Lifetime Warranty provided by the manufacturer
PRODUCT NUMBER: FO4320
ELECTRIC ACTUATORS - Adjustable upper hinge. Completely waterproof, submersible, and maintenance-free. Each 12-volt actuator comes with 6 ft wire harnesses and waterproof connectors. Mfg. PN# BEA3000 - Actuator stroke: 2.5" | Tip-to-tip length: 13.75". The system is designed for typical transom angles between 10-15 degrees, with compatibility extending to outliers up to 17 degrees. At a 17-degree transom angle, the required vertical installation space needed is 13.7".
ROCKER SWITCH CONTROL - For electric systems only. Attractive ergonomic design with positive click action for precise trim tab adjustment. Mfg. PN# BRC4000.
ACTUATOR WIRE HARNESSES - Two 20 ft wire harnesses with waterproof connectors included. Mfg. PN# BAW2020.
HIGH PERFORMANCE TRIM CONTROL - Eliminates boat porpoising, improves stability at high speed, and helps the boat plane faster with better control and a smoother ride in rough water conditions.
SPECIFICATIONS:
Trim Tab Size: 12" x 9"
Voltage: 12 Volts
Trim Tab Actuator: Electric System
Actuator Stroke: 2.5"
Actuator Tip-to-tip length: 13.75"
Vertical transom Space Required: Adjustable Upper Hinge (BEA3000): The system is designed for typical transom angles between 10-15 degrees, with compatibility extending to outliers up to 17 degrees. At a 17-degree transom angle, the required vertical installation space needed is 13.7"
Actuator Chord: 6 Ft
Trim Tab Control Type: Rocker Switch
Working forces: Actuation force: 750Lb. | Return Force: 750Lb. (This is max capacity; typically operates at 250 lbs)
Current draw: 10 - 30 Amp - 30 Amp max - will usually never get to this point
Type: Trim Tab Kits (Edge Mount)
Mounting Hardware: Mounting Hardware (Included)
Warranty Details: Limited Lifetime Warranty provided by the manufacturer
PRODUCT NUMBER: FO4320
